Brand Name: Komatsu
Model Number: 569-50-8T305
Payment & Shipping Terms
Minimum Order Quantity: 10 Pcs/Accept trial order
Price: Negotiable
Packaging Details: PP Bag Inside.outer is carton with film wrapped.
Delivery Time: Within 5-15 days after getting your desposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000SET
Part No.: |
569-50-8T305 |
Kit NO.: |
569508T305 |
Machine: |
Komatsu HD605-7 |
Product Name: |
FRONT AXLE CYLINDER SERVICE KIT |
Rod Size: |
160mm |
Rod Size: |
180mm |
Material: |
NBR,PU,SPCC,PFTE |
Temperature Range: |
-20 To +150 ℃ |
Color: |
Blue,yellow,black |
Part No.: |
569-50-8T305 |
Kit NO.: |
569508T305 |
Machine: |
Komatsu HD605-7 |
Product Name: |
FRONT AXLE CYLINDER SERVICE KIT |
Rod Size: |
160mm |
Rod Size: |
180mm |
Material: |
NBR,PU,SPCC,PFTE |
Temperature Range: |
-20 To +150 ℃ |
Color: |
Blue,yellow,black |
1. Repair Seal Kit Details
Part NO | 569-50-8T305 569508T305 |
Machine | Komatsu HD605 |
Size | 160mm |
Material | PU/NBR/SPCC |
Oil seal type | HOIST CYLINDER SERVICE KIT |
2. 569-50-8T305 PART NO. ON FRONT AXLE CYLINDER:
Pos. | Part No | Qty | Parts name |
8. | 01010-61085 | [15] | Bolt |
21. | 01010-81225 | [2] | Bolt |
34. | 01010-81020 | [2] | Bolt |
37. | 01010-81025 | [3] | Bolt |
10. | 566-50-11290 | [1] | Bushing |
12. | 569-50-6A181 | [1] | Bushing |
17. | 566-52-41920 | [1] | Bushing |
27 | 566-50-11340 | [1] | Cap |
26 | 281-50-11721 | [1] | Core, Valve |
32. | 569-50-81540 | [1] | Cover |
33. | 569-50-81550 | [1] | Cover |
1. | 569-50-81112 | [1] | Cylinder |
3. | 569-50-65140 | [1] | Flange |
6. | 07000-15190 | [1] | O-ring |
28 | 07000-11006 | [1] | O-ring |
16. | 07000-12060 | [2] | O-ring |
23. | 07000-13045 | [2] | O-ring |
36. | 07000-15145 | [1] | O-ring |
14. | 566-50-6A410 | [1] | Packing |
30. | 566-50-11350 | [3] | Packing |
19. | 566-50-11141 | [1] | Plate |
31. | 566-50-41310 | [1] | Plate |
4. | 07043-00108 | [1] | Plug, Taper |
5. | 566-50-11133 | [1] | Retainer |
7. | 07001-05190 | [1] | Ring, Back-up |
24. | 07001-03045 | [2] | Ring, Back-up |
13. | 707-51-16650 | [1] | Ring, Buffer |
18. | 04065-09030 | [2] | Ring, Snap |
11. | 566-50-11173 | [1] | Ring, Wear |
2. | 569-50-81031 | [1] | Rod Assembly |
2 | 569-50-81130 | [1] | Rod,Front |
15. | 569-50-81510 | [1] | Seal |
569-50-61413 | [1] | Stopper | |
569-50-8T305 | [1] | Suspension Assembly | |
20. | 569-50-61320 | [1] | Tube |
24. | 566-50-11301 | [1] | Valve Assembly |
25 | 566-50-11320 | [1] | Valve |
29. | 566-50-21260 | [1] | Valve |
9. | 01643-51032 | [15] | Washer |
22. | 01643-51232 | [2] | Washer |
3. Picture viewing for 569-50-8T305:
4. SERVICE KIT NO. AND PART NO.
SERVICE KIT No. | PART No. | Part No. |
569-50-8T305 |
569-63-62140 |
707-01-25010 |
6710-81-4231 | 569-50-41114 | 3F0599600 |
566-35-43711 | 569-50-61113 | 07000-71007 |
566-35-43710 | 569-50-62112 | 707-01-25010 |
6164-71-7542 | 21W-63-66740 | 21W-63-02220 |
569-63-62190 | 21W-63-66741 | 21W-63-02221 |
