195-15-71240 1951571240 Sealing Ring Construction Machinery Parts D375A-5 D375A-5E0

Name: 195-15-71240 1951571240 Sealing Ring Construction Machinery Parts D375A-5 D375A-5E0
Brand: Guangzhou Opal Machinery Parts Operation Department
SKU: 195-15-71240
Price: 34.10 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: OUB

Certification: ISO9001

Model Number: 195-15-71240

Payment & Shipping Terms

Minimum Order Quantity: 10

Price: Negotiable

Packaging Details: PP Bag Inside.outer is carton with film wrapped.

Delivery Time: Within 5-15 days after getting your desposit

Payment Terms: L/C,D/A,D/P,T/T,Western Union

Supply Ability: 1000Pcs

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                D375A-5 sealing ring construction machinery, D375A-5E0 gasket kit heavy equipment, sealing ring for D375A-5 bulldozer


Part No.::	195-15-71240	Model:	D375A-5E0
Part Name::	GASKET	Fits For:	TORQUECONVERTER
Machine:	Crawler Dozer	Material:	Oil-resistant Composite Paper, NBR Coated Composite Material
Color:	YELLOW

Part No.::	195-15-71240
Model:	D375A-5E0
Part Name::	GASKET
Fits For:	TORQUECONVERTER
Machine:	Crawler Dozer
Material:	Oil-resistant Composite Paper, NBR Coated Composite Material
Color:	YELLOW

Product Description

1. Quick Details of seal 195-15-71240 :

Part NO.	195-15-71240
Machine	Crawler Dozer
Size	OEM
Material	Oil-resistant composite paper, NBR coated composite material
Oil seal type	SERVICE KIT,TORQUECONVERTER

2. 195-15-71240 parts on group :

195-15-71240 1951571240 Sealing Ring Construction Machinery Parts D375A-5 D375A-5E0 0

NO.	PART NO.	PRAT NAME	QTY
1	195-15-71001	TRANSMISSION ASSEMBLY	1
2	195-15-71210	COVER	1
3	195-15-71240	GASKET (K2)	1
4	01010-81030	BOLT	12
5	01643-31032	WASHER	12
6	01643-31032	WASHER	1
7	01643-31032	WASHER	2
8	01011-81035	BOLT	1
9	01011-81035	BOLT	2
10	195-15-71270	COVER	1
11	195-15-71230	GASKET (K2)	1
12	195-15-71260	PLATE	1
13	01010-81035	BOLT	7
14	01643-31032	WASHER	7
15	195-15-75640	BLOCK	1
16	07043-70211	PLUG	1
17	07000-73028	O-RING (K2)	1
18	01010-81030	BOLT	2
19	01643-31032	WASHER	2
20	195-15-75631	SLEEVE	1
21	195-15-75750	O-RING (K2)	1
22	07000-72014	O-RING (K2)	1
23	07000-72016	O-RING (K2)	1

3. 195-15-71240 picture:

195-15-71240 1951571240 Sealing Ring Construction Machinery Parts D375A-5 D375A-5E0 1
4. Service part number :

PART NO.	PART NO.	Part NO.
707-35-52670	707-51-45640	707-99-75600
707-51-45640	707-51-11640	707-51-80640
707-51-50640	707-99-43690	707-98-36600
707-35-91850	707-99-43730	707-98-36700
707-51-11650	707-99-43740	707-51-16030
707-51-11690	707-51-11690	707-51-16030
707-51-12630	707-51-80030	707-98-27100
707-51-12640	707-51-80110	707-98-25920
707-51-12650	707-51-80211	707-98-25970
707-35-93020	707-51-85130	707-98-25980
707-35-99500	707-51-85030	707-51-18030
707-35-52830	707-44-10911	707-51-18030
707-35-52860	707-98-60120	707-98-58240
707-51-70650	707-98-60121	707-51-20250
707-99-77240	707-98-61100	707-35-52700

5. FAQ

Q: Where is this gasket set installed?
A: It is installed in a dedicated gland groove on the housing or liner bore. The backup ring is placed in the groove first, followed by the O-ring, forming a high-pressure seal between the liner and the housing.

Q: What happens if the dimensions are slightly off?
A: If the O-ring is too small, it won’t create enough compression to seal, leading to leaks. If it’s too large, it will be overstretched during installation, causing permanent deformation. A mis-sized backup ring won’t support the O-ring properly, allowing it to extrude under pressure.

Q: What happens if it’s installed backwards?
A: Installing the backup ring on the wrong side or misaligning the O-ring disrupts the designed sealing geometry. This prevents the system from handling high pressure, leading to immediate leaks and early failure of the O-ring.

Q: What happens if the set isn’t replaced in time?
A: Over time, the rubber O-ring will harden, lose elasticity, or develop cracks from heat and pressure. Without a new seal, the system will develop leaks, lose pressure, and eventually fail to operate. The PTFE ring can also wear, losing its ability to support the O-ring.

6. Exhibition and Wearhous
