113-15-11641 1131511641 High Quality Engine Filters D61EX-12 D58P-1

Name: 113-15-11641 1131511641 High Quality Engine Filters D61EX-12 D58P-1
Brand: Guangzhou Opal Machinery Parts Operation Department
SKU: 113-15-11641
Price: 34.10 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: OUB

Certification: ISO9001

Model Number: 113-15-11641

Payment & Shipping Terms

Minimum Order Quantity: 10

Price: Negotiable

Packaging Details: PP Bag Inside.outer is carton with film wrapped.

Delivery Time: Within 5-15 days after getting your desposit

Payment Terms: L/C,D/A,D/P,T/T,Western Union

Supply Ability: 1000Pcs

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                Gasket Kit engine filters D61EX-12, Gasket Kit engine filters D58P-1, Gasket Kit engine filters with warranty


Part No.::	113-15-11641	Model:	D58P-1B
Part Name::	GASKET	Fits For:	TORQUECONVERTER
Machine:	Crawler Tractors	Material:	Oil-resistant Compressed Fiber Composite Gasket Paper
Color:	YELLOW,GREY

Part No.::	113-15-11641
Model:	D58P-1B
Part Name::	GASKET
Fits For:	TORQUECONVERTER
Machine:	Crawler Tractors
Material:	Oil-resistant Compressed Fiber Composite Gasket Paper
Color:	YELLOW,GREY

Product Description

1. Quick Details of seal 113-15-11641:

Part NO.	113-15-11641
Machine	Crawler tractors
Size	OEM
Material	Oil-resistant compressed fiber composite gasket paper
Oil seal type	SERVICE KIT,TORQUECONVERTER

2. 113-15-11641 parts on group :

113-15-11641 1131511641 High Quality Engine Filters D61EX-12 D58P-1 0

NO.	PART NO.	PRAT NAME	QTY
1	134-15-00203	TRANSMISSION ASSEMBLY	1
2	134-15-21411	LEVER	1
3	134-15-11480	LEVER	1
4	134-15-11430	COLLAR	1
5	125-15-11430	COLLAR	1
6	06120-02016	BEARING,NEEDLE	4
7	144-15-29110	SEAL,OIL	2
8	144-15-25570	WASHER	2
9	135-15-31420	LEVER	1
10	125-15-11492	LEVER	1
11	125-15-11530	BOLT	2
12	125-15-11520	LOCK	2
13	125-15-11440	LEVER	1
14	144-15-25670	BUSHING	1
15	144-15-29121	BEARING	2
16	144-15-29120	BEARING	2
17	144-15-25691	PIN,ROLL	1
18	175-15-45660	WASHER	2
19	134-15-21450	BOLT	1
20	07000-72015	O-RING	1
21	01580-11008	NUT	1
22	01602-21030	WASHER,SPRING	1
23	135-15-31470	SPRING	1
24	125-15-11461	BOLT	1
25	01580-11008	NUT	1
26	01602-21030	WASHER,SPRING	1
27	134-15-21610	COVER	1
28	07030-10252	BREATHER	1
29	125-15-21640	PLATE	1
30	113-15-11641	GASKET	1
31	113-15-11640	GASKET	1
32	01580-11008	NUT	1
33	01602-21030	WASHER,SPRING	2
34	04020-00820	PIN,DOWEL	2
35	135-15-31621	GASKET	1
36	135-15-31620	GASKET	1
37	01010-51035	BOLT	4
38	01010-51025	BOLT	10
39	01602-21030	WASHER,SPRING	14

3. 113-15-11641 picture:

113-15-11641 1131511641 High Quality Engine Filters D61EX-12 D58P-1 1
4. Service part number :

PART NO.	PART NO.	Part NO.
707-35-52670	707-51-45640	707-99-75600
707-51-45640	707-51-11640	707-51-80640
707-51-50640	707-99-43690	707-98-36600
707-44-90080	707-51-12630	707-51-80030
707-44-90180	707-51-12640	707-51-80110
707-51-75211	707-51-11030	707-51-16030
707-51-80030	707-51-11110	707-98-27100
707-51-80110	707-51-11860	707-51-16130
707-51-80211	56D-50-13170	707-51-17030
707-51-85130	56D-50-13171	707-51-17130
707-51-85030	707-51-11050	707-51-18030
707-35-52830	707-51-80211	56D-50-13170
707-35-52860	707-51-85130	56D-50-13171
707-51-70650	707-51-85030	707-51-11050
707-99-77240	707-98-61100	707-35-52700

5. FAQ

Q: Which Komatsu machines does this gasket fit?
A: It is designed for Komatsu heavy equipment, primarily D-series bulldozers such as the D65 and D85, and other crawler tractors with matching powertrain or hydraulic system configurations.

Q: What material is this gasket made of?
A: It is constructed from a high-grade, oil-resistant compressed fiber composite (gasket paper). The nitrile-impregnated material offers excellent heat stability, compressibility, and resistance to hydraulic fluids and engine oils.

Q: What is the main function of this gasket?
A: Its core purpose is to create a static, leak-proof seal between mating components, typically a hydraulic pump, control valve, or related powertrain housing. It prevents fluid leaks and keeps contaminants out of the system.

Q: What colors are these gaskets?
A: They are available in two colors in this set: brownish-tan (the primary fiber grade) and black (a similar but different grade of the same material family).

Q: What is the structure of this gasket?
A: It is a precision-cut, two-bolt flange-style gasket with a central opening for fluid flow. The shape is asymmetrical to match the exact geometry of the mating parts.
